WS 500M Mobile Diesel Electric Hybrid Scrap Metal Shear Ideal for Scrap Yards and Metal Recycling Industry Applications

  • WS 500M Mobile Diesel Electric Hybrid Scrap Metal Shear Ideal for Scrap Yards and Metal Recycling Industry Applications
Plaats van herkomst Jiangsu, China
Merknaam DLK
Certificering CE, ISO 9001
Modelnummer WS-500M
Min. bestelaantal 1 Instellen
Prijs USD 98000-110000 per Set
Verpakking Details Zelftransporttrailer, beschermende verpakking voor zeevracht
Levertijd 30-40 werkdagen
Betalingscondities L/C, T/T
Levering vermogen 8 reeksen per maand
Productdetails
Model WS-500M Vermogenstype Hybride elektrisch + diesel
Max Cutting Force 500 ton Bladlengte 1400 mm
Scheerbeurthoogte 300/420 mm Elektromotor 74 kW 380V/3P
Dieselmotor 120 PK Deutz Brandstoflooptijd 16 uur (tank van 400 liter)
Mobiliteit Geïntegreerd aanhangerchassis Controle PLC + draadloze afstandsbediening
Laat een bericht achter
Productomschrijving
WS 500M Mobile Diesel Electric Hybrid Scrap Metal Shear Ideal for Scrap Yards and Metal Recycling Industry Applications
The WS-500M is a truly mobile scrap metal shear with a dual diesel-electric hybrid power system. Unlike conventional shears that require fixed power infrastructure, the WS-500M can operate on grid electricity when available or switch to its onboard diesel engine for remote locations without power access. The integrated trailer chassis allows rapid deployment between scrap yards.
Mobility & Power Flexibility
  • Dual Power Modes: 74 KW electric motor for grid operation + 120 HP diesel engine for off-grid sites
  • Seamless Power Switching: Automatic transfer between electric and diesel modes without interrupting operation
  • Integrated Trailer Chassis: Highway-towable design with standard fifth-wheel or ball hitch connection
  • No Foundation Required: Built-in hydraulic stabilizers deploy for level operation on any firm ground
  • Quick Deployment: Ready to operate within 30 minutes of arrival on site
  • Compact Container Style: 20-foot container footprint for easy transport by truck, rail, or ship
Applications
Perfect for mobile scrap processing services, temporary demolition sites, remote mining operations,base recycling, disaster cleanup operations, and multi-yard operators who move equipment between locations.
Technical Specifications
Parameter Specification
Model WS-500M
Power Type Hybrid (Electric + Diesel)
Max Cutting Force 500 Tons
Blade Length 1400 mm
Shear Height 300/420 mm
Cutting Speed 3-4 times/min
Processing Capacity 6-9 tons/hour
Electric Motor Power 74 KW (380V/3P 50Hz)
Diesel Engine Power 120 HP (Deutz Tier 3)
Fuel Tank Capacity 400 Liters (approx. 16 hours runtime)
Pump Type A4V250
Hydraulic System Pressure ≤ 26 MPa
Control System PLC + Wireless Remote Control
Cooling System Hydraulic Oil Cooler + Engine Radiator
Mobility Integrated Trailer Chassis with Stabilizers
Transport Dimensions 6200 x 2500 x 2800 mm
Machine Weight 28 Tons
Our Service
  • 24/7 global technical support via phone and remote access
  • One year comprehensive warranty on all components including engine
  • Worldwide spare parts delivery within 72 hours
  • On-site commissioning and operator training available
  • Custom diesel engine options (Deutz, Perkins) available
Contact us for a mobile demonstration at your location.
