Q15B-2500 Gantry Plate Hydraulic Shear Machine with 250 Ton Max Shear Force and 1200/1600mm Blade Length for 25/20*1000mm Cutting

  • Q15B-2500 Gantry Plate Hydraulic Shear Machine with 250 Ton Max Shear Force and 1200/1600mm Blade Length for 25/20*1000mm Cutting
  • Q15B-2500 Gantry Plate Hydraulic Shear Machine with 250 Ton Max Shear Force and 1200/1600mm Blade Length for 25/20*1000mm Cutting
Certificering ISO
Min. bestelaantal 1
Prijs 14300

Contacteer me voor vrije steekproeven en coupons.

Whatsapp:0086 18588475571

wechat: 0086 18588475571

Skype: sales10@aixton.com

Als u om het even welke zorg hebt, verstrekken wij de online-Help van 24 uur.

x
Productdetails
Maximale scheerkracht 250 (ton) Bladlengte 1200/1600 (mm)
Max snijden 25/20*1000 (mm) Scheerfrequentie 4-7 (tijden/min)
Motorvermogen 2*18,5 (kW) Nominale kracht 120 ton ~315 ton
Gedreven type Hydraulisch Spanning 21,5 mpa
Automatische rangschikking Halfautomatisch Schuifkracht 250 (ton)
Maximaal materiaal 30/25*1000 (mm) Vermogensbereik 15 kW ~ 44 kW
Productiecapaciteit 5 sets/maand Modelnummer Q15B-2500
HS-code 8462399000
Markeren

250 Ton Max Shear Force Gantry Shear

,

1200/1600mm Blade Length Hydraulic Shear Machine

,

25/20*1000mm Max Cutting Specifications Plate Shear
Laat een bericht achter
Productomschrijving
Q15b-2500 Gantry Plate Hydraulic Shear Machine
This hydraulic shear machine is designed for processing various metal plates, cutting them into materials of different specifications. It effectively replaces flame cutting methods while significantly reducing operational costs.
Product Information
Model Number: Q15-1200~Q15-3150
Certification: SGS
Place of Origin: Jiangsu P.R. China
Technical Specifications
Product Name: Gantry plate shear
Condition: New
Application: Scrap metal
Nominal Force: 120Tons ~315Tons
Driven Type: Hydraulic
Power: 15KW~44kW
Voltage: 21.5Mpa, Customized
Color: Customized
Automatic Grade: Semi-Automatic
Commercial Terms
Minimum Order Quantity: 1 Set
Price: Negotiable
Payment Terms: 30% T/T In Advance
Supply Ability: 10 sets/month
Delivery Time: As per requirement
Packaging Details: Seaworthy packing
After-sales Service: Engineers available for overseas service
Model Specifications
Model Shearing Force (ton) Blade Length (mm) Max. Cutting Material (mm) Shearing Frequency (times/min) Motor (KW)
Q15A-1200 120 600 18×500 4-7 15
Q15A-1600 160 600 20×500 4-7 18.5
Q15A-2000I 200 600/800 25×500 4-7 22
Q15A-2500I 250 600 30×500 4-7 22
Q15A-2500II 250 800 30×700 4-7 2×15
Q15A-3150 315 800 30×700 4-7 45
Q15A-4000 400 800 35×700 4-7 2×22
Q15A-5000 500 900 40×800 4-7 2×45
Q15B-1600 160 1200 16/12×1000 4-7 18.5
Q15B-2000 200 1200 18/16×1000 4-7 22
Q15B-2500I 250 1200/1600 25/20×1000 4-7 2×18.5
Q15B-3150 315 1200 30/25×1000 4-7 2×18.5
