Q15A-2500ll Gantry Plate Shear Machine with 800mm Blade Length and 30*700mm Max Cutting at 4-7 Times/Min

  • Q15A-2500ll Gantry Plate Shear Machine with 800mm Blade Length and 30*700mm Max Cutting at 4-7 Times/Min
  • Q15A-2500ll Gantry Plate Shear Machine with 800mm Blade Length and 30*700mm Max Cutting at 4-7 Times/Min
Min. bestelaantal 1
Prijs 1

Contacteer me voor vrije steekproeven en coupons.

Whatsapp:0086 18588475571

wechat: 0086 18588475571

Skype: sales10@aixton.com

Als u om het even welke zorg hebt, verstrekken wij de online-Help van 24 uur.

x
Productdetails
Model-NR. Q15A-2500ll Bladlengte 800 (mm)
Max. Snijspecificaties 30*700 (mm) Scheerfrequentie 4-7 (tijden/min)
Motor 2*15 (kW) Nominale kracht 120 ton ~315 ton
Gedreven type Hydraulisch Stroom 15 kW ~ 44 kW
Spanning 21.5Mpa, Aangepast Automatische rangschikking Halfautomatisch
Schuifkracht 250 (ton) Max. Materiaal 30*700 (mm)
Productiecapaciteit 10 sets/maand Motorvermogen 2*15 (kW)
Markeren

800mm Blade Length Gantry Shear

,

30*700mm Max Cutting Plate Shear Machine

,

4-7 Times/Min Shearing Frequency Gantry Plate Shear
Laat een bericht achter
Productomschrijving
Q15A-2500ll Gantry Plate Shear Machine
This hydraulic gantry plate shear machine is engineered for processing various metal plates, efficiently shearing them into materials of different specifications. It serves as a superior alternative to flame cutting methods, significantly reducing operational costs while maintaining precision and productivity.
Product Information
Model Number: Q15-1200~Q15-3150
Certification: SGS
Place of Origin: Jiangsu P.R. China
Technical Specifications
Product Name: Gantry Plate Shear
Condition: New
Application: Scrap Metal Processing
Nominal Force: 120Tons ~ 315Tons
Driven Type: Hydraulic
Power: 15KW ~ 44kW
Voltage: 21.5Mpa, Customized
Color: Customized
Automatic Grade: Semi-Automatic
Commercial Terms
Minimum Order Quantity: 1 Set
Price: Negotiable
Payment Terms: 30% T/T In Advance
Supply Ability: 10 Sets/Month
Delivery Time: As Per Requirement
Packaging Details: Seaworthy Packing
After-sales Service: Engineers Available for Overseas Service
Detailed Model Specifications
Model Shearing Force (ton) Blade Length (mm) Max. Cutting Material (mm) Shearing Frequency (times/min) Motor (KW)
Q15A-1200 120 600 18×500 4-7 15
Q15A-1600 160 600 20×500 4-7 18.5
Q15A-2000I 200 600/800 25×500 4-7 22
Q15A-2500I 250 600 30×500 4-7 22
Q15A-2500II 250 800 30×700 4-7 2×15
Q15A-3150 315 800 30×700 4-7 45
Q15A-4000 400 800 35×700 4-7 2×22
Q15A-5000 500 900 40×800 4-7 2×45
Q15B-1600 160 1200 16/12×1000 4-7 18.5
Q15B-2000 200 1200 18/16×1000 4-7 22
Q15B-2500I 250 1200/1600 25/20×1000 4-7 2×18.5
Q15B-3150 315 1200 30/25×1000 4-7 2×18.5
Q15A-2500ll Gantry Plate Shear Machine with 800mm Blade Length and 30*700mm Max Cutting at 4-7 Times/Min 0
